Features of the system
1, using the latest 32 bit Cortex-M3 kernel processor, the running speed is single cycle 72M;
2, 5 pulse output up to 1OOK, pulse type "pulse + direction", open collector
Output current is up to 200mA;
3, 7 high speed input point! Response time is less than 2uS,
4, 4 collector circuit, open circuit output, output current 5A:
5, the board integrates the standard RS485 communication interface, and is equipped with Modbus RTU communication protocol
To facilitate contact with various brands of touch screen communications, data format for 38400, 8, N, 1;
6 、 the driver of the stepping motor is equipped with a rectifier circuit to provide the 15A driver for the driver
The current causes the circuit wiring of the machine to be simpler; the rectifier circuit is stopped when the machine is stopped
Output; can adjust the mechanical part in the case of constant power:
7, with large capacity memory, you can save 100 sets of parameters at the same time to facilitate operator operation;
